17.9 Removable Media (RM) Function Blocks in Cscape
NOTE: For detailed information regarding RM function blocks and parameters, refer to the
Help File in Cscape Software. Refer ‘USB Flash Media support for RM Functions’ for USB flash
drive access details.
The following RM functional blocks are available in Cscape Software. These function blocks will
reference:
- microSD when filename is prefixed with ‘A:’ or nothing OR
- USB A Flash Drive when filename is prefixed with ‘B:’.
Read RM csv
Allows reading of a comma-separated value file from the microSD
interface into the controller register space.
Write RM csv
Allows writing of a comma-separated value file to the microSD
interface from the controller register space.
Rename RM csv
Allows renaming a file on the RM card. The data in the file is not
changed.
Delete RM csv
Allows deleting a file on the RM card
Copy RM csv
Allows copying a file on the RM card. The data in the file is not
changed.
Table 17.1 – RM Functional Blocks
17.10 Removable Media (RM) Features—Program Features
a. Datalog Configuration—This feature allows the controller to periodically log register values
to Removable Media. The register data is stored in .CSC (comma separated value) format,
which is compatible with 3
rd
party PC applications, such as Microsoft Excel.
b. Report Editor—This feature allows the OCS to be configured to generate text printouts
which incorporate data from the registers embedded in the text. The reports can be printed
using a serial interface printer through any of the serial ports of the OCS or can be saved on
the removable media of the device.
c. Recipes Editor—Recipes allow the user to send or update multiple registers simultaneously.
17.11 Removable Media (RM) Features—Graphic/Screen Editor
a. Trends—The historic support feature in the trend object utilizes Removable Media.
b. Removable Media—This is a graphic object used to access files and functions pertaining to
Removable Media.
c. Recipes—This is a graphic object that is used in conjunction with the recipe editor which is
mentioned above.
