Table 6.3 – %SR Registers – Master %SR Table
Register
Default I/O
Name
Description
Min-Max
Values
Program
(Read/Write)
Display
(Read/Write)
F10 = 10
F11= 11
F12 = 12
Enter = 13
+/ - = 14
. (dot) = 15
0 = 16
1 = 17
2 = 18
3 = 19
4 = 20
5 = 21
6 = 22
7= 23
8 = 24
9 = 25
System = 26
Escape = 27
Left = 28
Right = 29
Up = 30
Down = 31
Shift = 32
Soft Key 1 = 34
Soft Key 2 = 35
Soft Key 3 = 36
Soft Key 4 = 37
Soft Key 5 = 38
Soft Key 6 = 39
Soft Key 7 = 40
Soft Key 8 = 41
Release = 255 (Keys pressed since
power-up but not currently)
*Excludes RCC Units
%SR57
LCD Backlight Dimmer Register
0-100 = 0% to 100% On
100-255 = 100% On
*Excludes RCC Units
0 to 255
Read/Write
Read/Write
%57.16
Temporarily disable Screen Saver
*Excludes RCC Units
Read/Write
Read/Write
%SR58
USER_LEDS
User LEDs
Read/Write
Read/Write
%SR59
Engine Build Number (Only last three
numbers displayed)
Read Only
Read Only
%SR60
Build Option
Build Test = 0
Build Beta = 1
Build Product = 2
0 to 2
Read Only
Read Only
%SR61
NUM_IDS
Number of CsCAN Network IDs
Read Only
Read Only
%SR62-100
Reserved
%SR101.3
WebMI License Details – WebMI server
status
*XLEe, XLTe, X2, X4, & X7 only
Read Only
Read Only
%SR101.4
WebMI License Details – WebMI user
logged in status
*XLEe, XLTe, X2, X4, & X7 only
Read Only
Read Only
