Table 6.3 – %SR Registers – Master %SR Table
Register
Default I/O
Name
Description
Min-Max
Values
Program
(Read/Write)
Display
(Read/Write)
%SR164.6
EN_AUTO_LD
Enable AUTOLOAD – Sets “Enable
AutoLoad” to “Yes” or “Not”
Read / Write
Read / Write
%SR164.7
STRT_BCKUP
Start Backup trigger bit – Setting TRUE
starts backup of all register data
Read / Write
Read / Write
%SR164.8
CLR_BACKUP
Clear Backup trigger bit – Setting TRUE
clears backup of all register data (if a
backup was done previously)
Read / Write
Read / Write
%SR164.9
MAKE_CLONE
MAKE_CLONE trigger bit = Setting
TRUE does a Load Clone (if a media
card is present)
Read / Write
Read / Write
%SR164.10
LOAD_CLONE
LOAD_CLONE trigger bit – Setting TRUE
does a LOAD CLONE (if a media card is
present that contains clone files)
Read / Write
Read / Write
%SR164.11
MK_CLN_FL
Make Clone Fail (This bit goes high
when Make/Create Clone fails)
Read / Write
Read / Write
%SR164.12
LD_CLN_FL
Load Clone Fail (This big goes high
when Load Clone fails)
Read / Write
Read / Write
%SR164.14
Set to 1 to restore data manually, and
this in turn sets %SR164.15 to 1.
Set to 0 to abort restore operation.
*RCC Units Only
Read / Write
Read / Write
%SR164.15
Set to 1 for manual restore of data.
Set to 0 to complete the restore
operation.
*RCC Units Only
Read / Write
Read / Write
%SR165-166
Reserved
%SR167
Screen Update Time, Default= 5
*X4 & X7 Only – Default = 10
2 to 50
Read/Write
Read/Write
%SR168-170
Reserved
%SR171
X-Coordinate Touched
Read Only
Read Only
%SR172
Y-Coordinate Touched
Read Only
Read Only
%SR173
System-Function Disable,
0 to 1
Read / Write
Read / Write
%SR174
Removable Media Protect
Read/Write
Read/Write
%SR174.1
Request Media Card be Removed
Read / Write
Read / Write
%SR174.2
Indicates safe to remove Media
Read / Write
Read / Write
%SR175
Removable Media - Status
Read Only
Read Only
%SR176-177
Removable Media Free Space (32-Bit
DINT)
Read Only
Read Only
%SR178-179
Removable Media Total Space (32-Bit
DINT)
Read Only
Read Only
%SR180
Reserved
%SR181
ALM_UNACK
Bits 1-16 indicate Unacknowledged
in Alarm Groups 1-16
Read Only
Read Only
%SR182
ALM_ACT
Bits 1-16 indicate Active
in Alarm Groups 1-16
Read Only
Read Only
%SR183
SYS_BEEP
Beep on Keypress Enable
0= Disabled
1= Enabled
0 to 1
Read / Write
Read / Write
%SR184
USER_BEEP
Internal Beeper
0=OFF
1=ON
0 to 1
Read/Write
Read/Write
%SR185
Screen Saver Enabled
0= Disabled
1= Enabled
0 to 1
Read Only
Read Only
