HORNER EXL6 0 - Page 95

MAN1032-10-EN_EXL6_UserManual
March 12, 2020 95 | 191
NOTE: Four Count Mode requires FPGA update.
Table 10.4 – HSC Functions Register Map for 4 HSC Configuration
Register
Frequency
Pulse
Totalize
%AI401-402
Accumulator - Counter 1
%AI403-404
Latch Value – Counter 1
%AI405-406
Accumulator – Counter 2
%AI407-408
Latch Value – Counter 2
%AI409-410
Accumulator – Counter 3
%AI411-412
Latch Value – Counter 3
%AI413-414
Accumulator – Counter 4
%AI415-416
Latch Value – Counter 4
%AQ401-402
Preload – Counter 1
%AQ403-404
Match1 – Counter 1
%AQ405-406
Match2 – Counter 1
%AQ407-408
Preload – Counter 2
%AQ409-410
Match1 – Counter 2
%AQ411-412
Match2 – Counter 2
%AQ413-414
Preload – Counter 3
%AQ415-416
Match1 – Counter 3
%AQ417-418
Match2 – Counter 3
%AQ419-420
Preload – Counter 4
%AQ421-422
Match1 – Counter 4
%AQ421-424
Match2 – Counter 4
%Q1601
Latch – Counter 1
%Q1602
Preload – Counter 1
%Q1603
Clear – Counter 1
%Q1604
Disable – Counter 1
%Q1605
Direction – C1
%Q1606
Output Reset – Counter 1
%Q1607
Preload Disable – Counter 1
%Q1608
Latch Disable – Counter 1
%Q1609-1616
Reserved
%Q1617
Latch – Counter 2
%Q1618
Preload – Counter 2
%Q1619
Clear – Counter 2
%Q1620
Disable – Counter 2
%Q1621
Direction – C2
%Q1622
Output Reset – Counter 2
%Q1623
Preload Disable – Counter 2
%Q1624
Latch Disable – Counter 2
%Q1625-1632
Reserved
%Q1633
Latch – Counter 3
%Q1634
Preload – Counter 3
%Q1635
Clear – Counter 3
%Q1636
Disable – Counter 3
%Q1637
Direction – C3
%Q1638
Output Reset – Counter 3
%Q1639
Preload Disable – Counter 3
%Q1640
Latch Disable – Counter 3
%Q1641-1648
Reserved
%Q1649
Latch – Counter 4
