Horton 4100-PLUS - Page 16

80
15
70
280
Pivot
55
95
45
112 188 188 112
25
64.5
362.5
292.5
25
Push Mounting Angle, KAS312 - 38x38x3
1
CW Mount Push Sht.3
Horton Automatics Ltd
Unit A - Hortonwood 31
Telford, Shropshire TF1 7YZ
Adam Wiggans
03/11/2016
SHEET 3 OF 3
SCALE:1:5
DESCRIPTION:
REVISION
DO NOT SCALE DRAWING
DATE:
DRAWN
DWG NO:
0104.4100-Plus S
Sht.3
DIMENSIONS IN MM
