4100-PLUS S
Parameters Table
ID
Description
Setting
Default
01
Opening speed
20°/s to 70°/s (5°/s steps)
60
02
Closing speed
10°/s to 40°/s (5°/s steps)
20
03
Hold open
0 to 60s. 62= 2min, 63=3min, 64=4min
0
04
Hold open ‘low-energy’
5 to 60s
5
05
Closing speed
1 to 9 max
5
06
Stop/reverse sensitivity
1 (sensitive) to 9, both directions
5
07
Acceleration / deceleration
5 to 30
30
08
Check speed angle
10 to 40
20
09
Electric lock power
0=12 VDC 1=24 VDC
0
10
Lock type
0 = No Lock, 1 = Strike fail secure without
power, 2 = Maglock (24VDC type only), 3 =
Solenoid, 4 = Motorised, 5 = strike with relock
at power off, 6 = Maglock with delay(24VDC)
0
11
Opening delay
0 to 9 set according to type of electric lock type
2
12
Lock closing force
0(min) to 9(max)
5
13
Single/Master/Slave
0= Single, 1= master, 2= slave
0
14
Lock activation / hold close
0 = Disabled 1 = One Radar
2 = Two Radars 3 = One and Two Radars
3
15
Auxiliary input 1
0 = DDA opening 1 = Emergency opening
2 = Interlock door with priority
3 = Interlock door without priority
4 = Feedback lock release
5 = Command lock release
6 = Command Single on Double door
7 = Stand-by
8 = Reactivate the door after stand-by
9 = Step/step function (impulse open/close)
10= Fire alarm 11= Manual
12= Stop closed
0
16
Auxiliary input 2
0 = DDA opening 1 = Emergency opening
2 = Interlock door with priority
3 = Interlock door without priority
4 = Feedback lock release
5 = Command lock release
6 = Command Single on Double door
7 = Stand-by
8 = Reactivate the door after stand-by
9 = Step/step function (impulse open/close)
10= Fire alarm 11= Manual
12=Stop closed
1
