Horton 4100-PLUS - Initiate Safety Sensor Monitoring

32
4100-PLUS S
Initialize Sensors
 Initialize sensors by pressing function switch until led turns off, then release
 Led will flash green indicating number of modules connected then flash
alternate yellow/red when initialisation is complete
Initiate Learn procedure
 Initiate a sensor learn by pressing function switch briefly, the Led indicator
will flash yellow whilst it ‘learns’ the non detection zone.
 Do not enter sensor detection zone during learn cycle.
 When complete the LED will show green and sensor goes to stand-by.
9. Initiate Safety Sensor Monitoring
Set sensor monitoring function to on and sensor input to normally closed
 check Aux Out 1 is set to PNP via adjacent jumper
ID
Description
Setting
17
Safety sensor monitoring
0 = monitoring ON
30
Auxiliary Out 1 state
1 = NC
Carry out Safety sensor learn procedure LS as described in Step 4
 During LS procedure keep clear of sensors else procedure will fail
 If sensors are incorrectly wired or set up, display flashes LS.
o Abort procedure by pushing ESC.
o Check sensors and launch LS again.
On completion of LS procedure the detected configuration is displayed until
either ENT is pressed to confirm the configuration is correct or ESC to abort.
Sensor Configurations
ID
Description
S0
No monitored sensors detected
S1
Monitored opening sensor detected
S2
Monitored closing sensor detected
S3
Monitored opening and closing sensors detected.
Adjust Sensor Blanking
Adjust safety sensor blanking angle via parameter 20 as necessary.
ID
Description
Setting
20
Safety sensor blanking
0 ÷ 40% of opening angle
