Horton 4100-PLUS - Set & Adjust Powered Operation

23
HORTON
5. Set & Adjust Powered Operation
Following a successful learn cycle, pressing [ENT] initiates a door cycle and
is used to check operation whilst commissioning without peripheral devices
connected.
Adjust parameter values 1 through 8 according to installation requirements
ID
Parameter
Range
Default
01
Opening speed
20°/s to 70°/s (5°/s steps)
60
02
Closing speed
10°/s to 40°/s (5°/s steps)
20
03
Hold open
0 ÷ 60sec, 62= 2min, 63=3min, 64=4min
0
04
Hold open low-energy
5 to 60sec (1sec steps)
5
05
Speed during Spring closing
(according to Dip 6)
1 (slow) to 9 (fast)
5
06
Stop/reverse sensitivity
1 (sensitive) to 9 (less sensitive)
5
07
Acceleration / deceleration
5 to 30
30
08
Check speed angle
10 to 40
20
Parameter setting values are altered via the push buttons.
To set values proceed as follows:
 Select parameter to adjust with push buttons [+] and [-]
 Press [ENT] to enter in the adjustment mode
 The current parameter value is indicated on display
 Press [+] and [-] to change value
 Press [ENT] to accept value
 Press [ESC] to memorise settings and exit adjustment mode.
Press [ESC] to exit adjustment mode without modification.
After 10 seconds of inactivity the system exits adjustment mode.
