22
Learn Cycle (LP)
A learn cycle is required to determine the limits of door movement. A
physical stop is required to find opening angle, this may be temporary.
Select LP via [+] & [‐]
Push [ENT] briefly
Display flashes [‐‐]
Push and hold [ENT] until display flashes E1 or opening cycle starts
The learn cycle will begin during which the door will cycle once.
On completion the display will indicate CL (closed position).
The operating opening angle will be reduced compared to the limit
detected during the learn cycle to allow operation if there is no physical
door stop. The percentage of reduction is defined by parameter 33.
