4100-PLUS S

COMMISSIONING POWERED OPERATION

1. Preliminary Checks

Before electrical wiring, complete following checks:

 Clear swarf and all other residual debris

 Verify security of all fixings

Control Board Layout

Fig.19 Control board layout

A. Display Orientation

B. Display and push buttons

C. Primary Function Dip switches

D. PC connector

E. Transformer plug connector

F. Battery connector

G. ON-OFF Switch connector

H. Integral Mode switch plug

I. Auxiliary Outputs

J. Input connections

K. Auxiliary power output

L. Pair & adv. mode selector link

M. Lock power output

N. Encoder

O. Motor

P. Brake Level

Q. Arm Type selector
