Operator Functions
Function
Description
Low-Energy Activation
With AUX IN 1 or 2 parameter 15 set to DDA Opening (0) an input
initiates a low energy cycle. (except in Stop Close)
Push & Go Activation
Powered operation starts when pushed. Selectable by DIP 3.
Closing Cycle Sensor ESPE
If activated the door stops briefly and recycles open.
Opening Cycle Sensor ESPE
If activated door movement stops.
Opening Cycle Obstruction
If obstructed whilst opening the door stops briefly then closes slowly.
Sensitivity is adjusted via parameter 6
Closing Cycle Obstruction
If obstructed whilst closing the door stops briefly then opens slowly.
Sensitivity is adjusted via parameter 6
Display Messages
The segmented display indicates operation and error codes:
Display
Meaning
OP
Door opened
OP (blinking)
Door opening
CL
Door closed
CL (blinking)
Door closing
E1
Door requires self-learning procedure
E2
Wrong arm selection – (Dip 1, Slide switch or Dip 5)
E3/E4
Over Current
E6
Monitored sensor error
E8
Encoder connection
S1
Opening safety monitoring fault
S2
Closing safety monitoring fault
S3
Opening and closing safety monitoring fault
Parameter Reset
To reset all parameter to factory default values:
 Select Sd via [+] & [‐]
 Push [ENT] briefly
 Display flashes [‐‐]
 Push and hold [ENT] until [--] disappears and release [ENT].
