Horton 4100-PLUS - Page 78

37
HORTON
ID
Description
Setting
Default
17
Auxiliary output 1
0 = Sensors monitoring
1 = Interlock
2 = Stop open condition
3 = Stop closed condition
4 = Failure
5 = Repetition of lock command
0
18
Auxiliary output 2
As Auxiliary output 1 configuration
1
19
Multi-Master
1 to 15 (see specific instructions)
0
20
Safety sensor blanking
0 – 40% of opening angle
0
21
Opening sequence delay
0 – 100ms delay (0=synchronized)
0
22
Closing sequence delay
0 – 100ms delay (0=synchronized)
0
23
Open safety input
0 = NO (Normally Open)
1 = NC (Normally Closed)
1
24
Close safety input
1
25
Key input
1
26
Start1
0
27
Start2
0
28
Aux In 1
0
29
Aux In 2
0
30
Aux Out 1
0
31
Aux Out 2
0
32
Force level during LP
5 to 60 (0 = min, 9 = max)
5
33
Opening angle reduction
0 to 50%
0
34
Mounting Position
0= lintel, 1= door
0
35
DDA speed
0= LE, 1= according to speed parameters 1 & 2
0
36
Battery back-up
0= no battery, 1= continuous operation, 2= open
0
37
START 2 function
0 = Powered operation, active according to mode
1 = LE operation, active in manual mode only
2 = LE operation, active in all modes
0
TS
Test cycle
0= none, 1= cyclical, 2= intensive cyclical
