Operating Modes
Integral Mode Switch
Mode Switch
Description
I – Manual
Manual operation, START 1 & 2 activation inputs are disabled
O – Automatic
Powered operation. START 1 & 2 activation inputs active
Locking / hold by motor function active dependent on P.14
II – Hold Open
Door Open
Remote Mode Switch (key-switch)
Mode Switch
Description
1 – Automatic
Powered operation. START 1 & 2 activation inputs active.
Locking / hold by motor function active, dependent on parameter 14.
2 – Off
Manual operation with spring closing when P.15 set to manual.
Start 1 & 2 activation inputs disabled. Key Input enabled
Locked (or held by motor P.14) when P.15 set to Stop/close.
Start 1 & 2 activation inputs disabled. Key Input enabled
3 – Hold Open
Door Open
Advanced Mode Switch (membrane switch)
Mode Switch
Description
Manual
Manual operation.
Automatic – 1 way
Only START 1 activation input is active.
Locking / hold by motor function active, dependent on parameter 14.
Automatic – 2 way
START 1 & 2 activation inputs are active.
Locking / hold by motor function active, dependent on parameter 14.
Stop Close
START 1, 2 and DDA inputs are disabled
Locking / hold by motor function dependent on parameter 14.
Hold Open
Door Open
