Horton 4100-PLUS - Page 19

15
80
280 70
Pivot
Pivot
112 188 188 112
64.5 45
112 188 188 112
55
95
70 55 292.5 70
25
95
292.5
Push Mounting Channel, KAS312 - 38x38x3
0
Curtain Wall Mount Push Pair Sht.3
Horton Automatics Ltd
Unit A - Hortonwood 31
Telford, Shropshire TF1 7YZ
Adam Wiggans
03/11/2016
SHEET 3 OF 3
SCALE:1:5
DESCRIPTION:
REVISION
DO NOT SCALE DRAWING
DATE:
DRAWN
DWG NO:
0104P.4100-Plus S
Sht.3
DIMENSIONS IN MM
