Horton 4100-PLUS - Page 6

5
5
86
90
25
35
(spindle + 5)
DETAIL C
PF18.06 – Standard Push Arm
1
Frame Mounted Standard Push Arm Sht.2
Horton Automatics Ltd
Unit A - Hortonwood 31
Telford, Shropshire TF1 7YZ
Adam Wiggans
03/11/2016
SHEET 2 OF 3
SCALE:1:2
DESCRIPTION:
REVISION
DO NOT SCALE DRAWING
DATE:
DRAWN
DWG NO:
0101.4100-Plus S
Sht.2
DIMENSIONS IN MM
