HP 205 G1 User Manual

Using f11 recovery tools
CAUTION: Using f11 completely erases hard drive contents and reformats the hard drive. All les that you
have created and any software that you have installed on the computer are permanently removed. The f11
recovery tool reinstalls the operating system and HP programs and drivers that were installed at the factory.
Software not installed at the factory must be reinstalled.
To recover the original hard drive image using f11:
1. If possible, back up all personal les.
2. If possible, check for the presence of the HP Recovery partition: From the Start screen, type C, and then
select Computer.
NOTE: If the HP Recovery partition is not listed, you must recover your operating system and programs
using the Windows 8.1 operating system media, and the Driver Recovery media (both purchased
separately). For additional information, see Using Windows 8.1 operating system media (purchased
separately) on page 102.
3. If the HP Recovery partition is listed, restart the computer, and then press esc while the company logo is
displayed. The computer Startup Menu displays.
4. Press f11 to select the System Recovery option.
5. Follow the on-screen instructions.
Using Windows 8.1 operating system media (purchased separately)
To order Windows 8.1 operating system media, go to http://www.hp.com/support, select your country or
region, and follow the on-screen instructions. You can also order the media by calling support.
CAUTION: Using Windows 8.1 operating system media completely erases hard drive contents and reformats
the hard drive. All les that you have created and any software that you have installed on the computer are
permanently removed. When reformatting is complete, the recovery process helps you restore the operating
system, as well as drivers, software, and utilities.
To initiate recovery using Windows 8.1 operating system media:
NOTE: This process takes several minutes.
1. If possible, back up all personal les.
2. Restart the computer, and then follow the instructions provided with the Windows 8.1 operating system
media to install the operating system.
3. When prompted, press any keyboard key.
4. Follow the on-screen instructions.
After the repair is completed:
1. Remove the Windows 8.1 operating system media, and then insert the Driver Recovery media.
2. Install the Hardware Enabling Drivers rst, and then install Recommended Applications.
102 Chapter 9 Backup and Recovery

HP 205 G1 Specifications

General

Full HD	No
LED backlight	-
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Processor cores	2
Processor model	E1-2500
Processor family	AMD E
Processor frequency	1.4 GHz
Processor manufacturer	AMD
Product type	All-in-One PC
Internal memory	4 GB
Memory slots type	SO-DIMM
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	500 GB
Storage drive interface	Serial ATA
Discrete graphics card model	Not available
On-board graphics card model	AMD Radeon HD 8240
On-board graphics card family	AMD Radeon HD 8000
Wi-Fi standards	Not supported
Ethernet LAN data rates	10, 100 Mbit/s
Headphone outputs	1
USB 2.0 ports quantity	4
Thunderbolt ports quantity	0
Operating system installed	Ubuntu Linux
Product color	Black, Silver
Country of origin	China
Total megapixels	- MP
AC adapter power	65 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	15 - 80 %
Sustainability certificates	ENERGY STAR
Cables included	AC

Weight and Dimensions

Depth (with stand)	72 mm
Width (with stand)	470 mm
Height (with stand)	329 mm
Weight (with stand)	5500 g
