Replacing the optical disc drive

Description Spare part number

DVD±RW drive 657958-001

Optical drive bezel 806247-001

The optical disc drive is located above the hard disc drive on the left side of the computer (when viewed from

behind).

The optical drive data cable connects to the SATA1 and SATA PWR1 system board connectors.

NOTE: The drive bracket is not spared. When replacing an optical drive, remove the bracket from the old

drive and install it on the new drive.

1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).

2. Remove the rear cover (see Rear cover on page 20).

3. Loosen the captive Phillips screw (1) that secures the hard drive cage to the computer, and then slide

the cage toward the edge of the chassis to disengage it from the connector, and remove it from the

computer (2).

NOTE: When replacing an optical drive, remove the bracket from the old drive and install it on the new

drive. The bracket is not spared.

26 Chapter 5 Removal and Replacement Procedures All-in One (AIO) Chassis
