2.5-inch hard drive:
a. Remove the four Phillips screws (1) that secure the drive adapter to the cage, and then slide the
drive out of the cage (2).
b. Remove the four Phillips screws that secure the drive to the adapter (1), and the slide the drive out
of the adapter (2).
To replace the hard drive, reverse the removal procedures.
NOTE: To install an optional 2.5-inch drive, you must
1. Mount the drive in a drive adapter
2. Screw the four mounting screws into the drive adapter
Replacing drives 25
