HP 205 G1 User Manual

Solving hard drive problems
Hard drive error occurs.
Cause Solution
Hard disk has bad sectors or has failed. 1. In Windows 7, click Start, click Computer, and right-click on
a drive. Select Properties, and then select the Tools tab.
Under Error-checking click Check Now.
In Windows 8.1, on the Start screen type e, and then select
File Explorer from the list of applications. In the left
column, expand Computer, right-click on a drive, select
Properties, and then select the Tools tab. Under Error
checking click Check.
In Windows 10, type file in the taskbar search box, and
then select File Explorer from the list of applications. In the
left column, expand This PC, right-click on a drive, select
Properties, and then select the Tools tab. Under Error
checking click Check.
2. Use a utility to locate and block usage of bad sectors. If
necessary, reformat the hard disk.
Disk transaction problem.
Cause Solution
Either the directory structure is bad or there is a problem with a
le.
In Windows 7, click Start, expand Computer, and right-click on a
drive. Select Properties, and then select the Tools tab. Under
Error-checking click Check Now.
In Windows 8.1, on the Start screen type e, and then click File
Explorer from the list of applications. In the left column, expand
Computer, right-click on a drive, select Properties, and then
select the Tools tab. Under Error checking click Check.
In Windows 10, type file in the taskbar search box, and then
select File Explorer from the list of applications. In the left
column, expand This PC, right-click on a drive, select Properties,
and then select the Tools tab. Under Error checking click Check.
Drive not found (identied).
Cause Solution
Cable could be loose. Check cable connections.
The system may not have automatically recognized a newly
installed device.
See reconguration directions in the Solving Hardware
Installation Problems on page 82 section. If the system still
does not recognize the new device, check to see if the device is
listed within Computer Setup. If it is listed, the probable cause is a
driver problem. If it is not listed, the probable cause is a hardware
problem.
If this is a newly installed drive, run the Computer Setup utility
and try adding a POST delay under Advanced > Power-On
Options.
Solving hard drive problems 69

HP 205 G1 Specifications

General

Full HD	No
LED backlight	-
Display diagonal	18.5 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Processor cores	2
Processor model	E1-2500
Processor family	AMD E
Processor frequency	1.4 GHz
Processor manufacturer	AMD
Product type	All-in-One PC
Internal memory	4 GB
Memory slots type	SO-DIMM
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	500 GB
Storage drive interface	Serial ATA
Discrete graphics card model	Not available
On-board graphics card model	AMD Radeon HD 8240
On-board graphics card family	AMD Radeon HD 8000
Wi-Fi standards	Not supported
Ethernet LAN data rates	10, 100 Mbit/s
Headphone outputs	1
USB 2.0 ports quantity	4
Thunderbolt ports quantity	0
Operating system installed	Ubuntu Linux
Product color	Black, Silver
Country of origin	China
Total megapixels	- MP
AC adapter power	65 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	15 - 80 %
Sustainability certificates	ENERGY STAR
Cables included	AC

Weight and Dimensions

Depth (with stand)	72 mm
Width (with stand)	470 mm
Height (with stand)	329 mm
Weight (with stand)	5500 g
