Speakers
Description Spare part number
Speakers 752343-001
The speakers are located at the bottom of the computer. Two separate speakers are each secured by two Torx
screws.
To remove the speakers:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).
2. Remove the rear cover (see Rear cover on page 20).
3. Remove two Torx screws (1) that secure each speaker to the computer.
4. Disconnect the speaker cable from the system board connector labeled SPKR (2).
5. Remove the speakers from the computer.
To install the speakers, reverse the removal procedures.
34 Chapter 5 Removal and Replacement Procedures All-in One (AIO) Chassis
