The system will operate in single channel mode if the SODIMM sockets are populated in one channel
only.
●
The system will operate in ex mode if the memory capacity of the SODIMM in Channel A is not equal to
the memory capacity of the SODIMM in Channel B. In ex mode, the channel populated with the least
amount of memory describes the total amount of memory assigned to dual channel and the remainder
is assigned to single channel. If one channel will have more memory than the other, the larger amount
should be assigned to channel A.
●
The system will operate in a higher-performing dual channel mode if the memory capacity of the
SODIMM in Channel A is equal to the memory capacity of the SODIMM in Channel B.
●
In any mode, the maximum operational speed is determined by the slowest SODIMM in the system.
There are two memory sockets on the system board located behind the memory access panel. To remove or
install memory modules:
To remove a memory module:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 19).
2. Place the computer face down on a soft at surface. HP recommends that you set down a blanket, towel,
or other soft cloth to protect the screen surface from scratches or other damage.
3. Remove the rear cover (see Rear cover on page 20).
4. Remove the system board cover (see System board cover on page 39).
5. To remove a memory module, press outward on the two latches on each side of the SODIMM (1), then
pull the SODIMM out of the socket (2).
The computer automatically recognizes the additional memory when you turn on the computer.
42 Chapter 5 Removal and Replacement Procedures All-in One (AIO) Chassis
