10. Disconnect the backlight cable from the display panel.
NOTE: Replace the backlight cable with the new backlight cable that comes with the new display panel
kit.
Remove the backlight cable from the defective panel before sending the panel back to the supplier.
11. Remove the four Torx screws (two on each side) that secure the display panel to the frame.
12. Lift the display panel from the frame.
To install a display panel, reverse the removal procedures.
Display panel 49
