Component Description
(4) HP Mini Mobile Drive Bay (select models only) Connects an optional HP Mini Mobile Drive.
(5) Security lanyard connector Attaches an optional security lanyard to the device.
NOTE: The security lanyard is designed to act as a
deterrent, but it may not prevent the device from being
mishandled or stolen.
Left-side components
Component Description
(1) Power connector Connects an AC adapter.
(2) USB port Connects an optional USB device.
(3) Vent Enables airflow to cool internal components.
NOTE: The device fan starts up automatically to
cool internal components and prevent overheating. It
is normal for the internal fan to cycle on and off during
routine operation.
(4) Expansion port Connects an optional VGA cable, which allows you to
connect an external VGA monitor or projector.
(5) Audio-out (headphone) jack/Audio-in (microphone)
jack
Produces sound when connected to optional powered
stereo speakers, headphones, earbuds, a headset, or
television audio. Also connects an optional headset
microphone.
WARNING! To reduce the risk of personal injury,
adjust the volume before putting on headphones,
earbuds, or a headset. For additional safety
information, refer to the Regulatory, Safety and
Environmental Notices.
NOTE: When a device is connected to the jack, the
device speakers are disabled.
(6) RJ-45 (network) jack Connects a network cable.
8 Chapter 2 Knowing the parts
