Connecting to a wired network
Connecting to a local area network (LAN) requires an 8-pin, RJ-45 network (Ethernet) cable (purchased
separately). If the network cable contains noise suppression circuitry (1), which prevents interference
from TV and radio reception, orient the circuitry end of the cable (2) toward the device.
To connect the network cable:
WARNING! To reduce the risk of electric shock, fire, or damage to the equipment, do not plug a modem
cable or telephone cable into an RJ-45 (network) jack.
1. Plug the network cable into the network jack (1) of the device.
2. Plug the other end of the cable into a network wall jack (2).
24 Chapter 4 Internet
