3-61
P
erformance T
ests
External 2Mb/s Mux/Demux (Options UKJ
, [USA], UKN, [USA])
21.
Ensure that the ratio of +ve and -v
e pulse amplitudes is between 0.95 and 1.05.
22.
Ensure that the ratio of +ve and -v
e pulse widths is between 0.95 and 1.05.
23.
Disconnect all test equipment.
