3-125
Performance Tests
Transmitted Jitter Amplitude Accuracy (Option UHK)
Transmitted Jitter Amplitude Accuracy (Option UHK)
Specifications
Data Rates 2.048 Mb/s, 8.448 Mb/s, 34.368 Mb/s,
139.264 Mb/s, 155.52 Mb/s (STM-1),
622.08 Mb/s (STM-4)
Overall Accuracy ± 5% ± range accuracy ± intrinsic jitter
Range 1 ± 0.01 UI
Range 10 ± 0.1 UI
Intrinsic Jitter 2 Mb/s ± 0.02 UI
Intrinsic Jitter 8 Mb/s ± 0.02 UI
Intrinsic Jitter 34 Mb/s ± 0.03 UI
Intrinsic Jitter 140 Mb/s 200 Hz to 5 kHz - ± 0.10 UI
5 kHz to 10 kHz - ± 0.05 UI
>10 kHz - ± 0.02 UI
Frequency Range 2 Hz to 4 MHz
Frequency Accuracy ± 1%
Corner and Cut-off Frequencies
Data Rate Corner Frequency Cut-off Frequency
2 Mb/s 13 kHz 102 kHz
8 Mb/s 50 kHz 422 kHz
34 Mb/s 210 kHz 840 kHz
140 Mb/s 5 kHz 4 MHz
