3-117
Performance Tests
STM-1/STM-4 Optical Interface (Options 130, 131)
STM-1/STM-4 Optical Interface (Options 130, 131)
NOTE An SDH Option must be fitted for this option to operate - see Appendix B.
Specification (Transmitter)
Specification (Receiver)
Description
The 51.84/155.52/622.08 MHz output of the optical transmitter is checked for
power level at 1310 nm (and 1550 nm wavelengths if Option131). The receiver
sensitivity is verified by attenuating the transmitter output and checking for no
Wavelength 130 - 1280 nm to 1330 nm,
131 - 1280 nm to 1330 nm or 1520 nm to 1565 nm
Power Output 1310 nm -10 dBm (Nominal).
1550 nm -1dBm (Nominal)
Line Coding NRZ
Safety Class Class 3A, FDA 21 CFR Ch.1 1040.10 and EN 60825
Data Rate 51.84 Mb/s, or 155.52 Mb/s or 622.08 Mb/s (Nominal)
Wavelength 1200 nm to 1600 nm
Maximum Input Power -8 dBm (for BER of 1.0E
-10
)
Line Coding NRZ
Sensitivity -34 dBm Minimum (STM-0 & STM-1),
- 28 dBm Minimum (STM-4)
(wavelength=1300nm, Modulation=100%,
Data=2
23
-1, BER=1.0E
-10,
2
23
-1 PRBS)
PMP Input 150mV pk-pk minimum
PMP Impedance Nominal 50Ω
