3-237
Performance Tests
Performance Test Record
Performance Test Record
Hewlett-Packard Model 37717C Communications Performance Analyzer
Location: Serial No.:
Tested by:
Temperature: Certified by:
Humidity: Date:
Table 11 Performance Test Record
Page
No.
Test Description Result
Min Actual Max
Self Test
3-3 Step 3 All Tests Pass/Fail
PDH Internal Transmitter Clocks
3-7 Step 5: 704 kb/s (UKK only) 351.99753 kHz 352.00246 kHz
Step 6: 2 Mb/s 1.0239928 MHz 1.0240072 MHz
Step 7: 8 Mb/s 4.2239704 MHz 4.2240296 MHz
Step 8: 34 Mb/s 17.1838797 MHz 17.1841203 MHz
Step 9: 140 Mb/s 69.6315126 MHz 69.6324874 MHz
Frequency Offset Bit Rates
140 Mb/s
3-8 Step 11: + 15 ppm 69.63255705 MHz 69.63353191 MHz
Step 12: - 15 ppm
69.63064218 MHz 69.63126886 MHz
Step 13: + 100 ppm
69.63864986 MHz 69.63927654 MHz
Step 14: - 100 ppm 69.62472346 MHz 69.625535014 MHz
