General Information
Recommended Test Equipment
Recommended Test Equipment
Instrument Critical Specification Recommended Model
Oscilloscope 400 MHz Bandwidth, 1 MΩ Input Termination HP 54503A
Spectrum Analyzer 200 MHz Bandwidth, 75Ω Input, -70 to +20 dBm HP 8568B Opt 001
Frequency Synthesizer 75Ω Output, Sinewave to 80 MHz,
Amplitude to2.5 V pk-pk, 1 Hz resolution
HP 3335A Opt 001
Frequency Synthesizer Sinewave to 2.5 MHz, Amplitude to 5V pk-pk,
1 Hz Resolution
HP 3325B (Qty 2)
Signal Generator Sinewave 700 kHz to 170 MHz, Amplitude 500 mV HP 8657B
Frequency Counter Range 0 to 200 MHz, 2 channels with accuracy
<0.1ppm. (Ratio Mode)
HP 5335A Opt 010
Optical Power Meter and
Sensor Module
Range -8 dBm to -15 dBm, Wavelength1270-1340 nm HP 8153A and HP
81536A
Dual Power Supply ±12V HP 6253A
Lightwave Receiver Wavelength 1300 to 1560 nm, Conversion Gain 750
volts/watt, Frequency Response < 3 dB down at 1 GHz.
HP 83422A
Optical Attenuator Wavelength 1200 - 1600 nm, Range 0 - 30 dB
FC/PC Optical Interface
Connector
Unique HP 81000FI
Optical Cables Unique HP 11871A (Qty 2)
Digital Transmission
Analyzer
Unique HP 3764A Option 006
PDH Structured Test Set Unique HP 37717B/C Opt UKJ
Digital Transmission
Frame Generator
Unique HP 37729A
Jitter Generation Module Unique HP 37717B/C Opt UHK
ThinkJet Printer HP-IB Interface HP 2225A
Attenuator 6 dB, 50Ω, 0 to 200 MHz HP 8491A Opt 006
