3-135
Performance Tests
Transmitted Jitter/Wander Amplitude Accuracy (Option A3K [A3Q])
Equipment Required
Pre-Adjustment Setup
Before carrying out any adjustments to the HP 37717C Jitter Transmitter Module,
perform the following pre-adjustment setup.
CAUTION This procedure uses the special display on the HP 37717C.
When using the display, ONLY modify the parameters shown.
Altering other parameters can damage instrument firmware - exit the
display after setup to prevent accidental damage.
1. Recall the HP 37717C DEFAULT SETTINGS as shown on 3-2.
2. Setup the HP 37717C display
as shown opposite.
Communications Performance Analyzer : HP 37717C Opt UHN
Spectrum Analyzer : HP 8568B Opt 001
Oscilloscope : HP 54503A
Modulation Analyzer : HP 9801A/B
Synthesizer : HP 3325B
75Ω/50Ω Matching Pad
: HP 11825B
MODULE DEBUG
MODULE DEBUG
MODULE DEBUG
OTHER
To Next Page
