3-68
Performance Tests
PDH Receiver Monitor Levels (Special Option 808)
PDH Receiver Monitor Levels (Special Option 808)
Specification
Description
Option 808 provides an equalized Monitor input. This is checked by attenuating the
synthesizer output level by an amount equivalent to the extra gain provided by the
Monitor Amplifier. The synthesizer is set to generate a sinewave at half the bit rate
which corresponds to a ternary all ones signal. The receiver should sync up with no
errors if PATTERN [ALL ONES] is selected.
Equipment Required
Procedure
1. Recall the HP 37717C DEFAULT SETTINGS as shown on 3-2.
2. Connect up the equipment as shown in Figure 3-32.
3. Set the oscilloscope to: TERMINATION - 1 MΩ PROBE - 1:1
Bit Rate Nominal Loss Equalization
at 1/2 Bit Rate
704 kb/s 20dB Flat 3dB
2.048 Mb/s 20dB Flat 3dB
8.448 Mb/s 20dB Flat 3dB
34.368 Mb/s 20dB Flat 6dB
139.264 Mb/s 20dB Flat 6dB
Synthesizer : HP 3335A option 001 (75Ω)
Oscilloscope : HP 54503A
