Performance Tests
Performance Test Record
Frequency Offset
34 Mb/s
3-12 Step 16: + 20 ppm 17.1842234 MHz 17.1844640 MHz
- 20 ppm 17.1835360 MHz 17.1837766 MHz
8 Mb/s
+ 30 ppm 4.2240972 MHz 4.2241563 MHz
- 30 ppm 4.2238437 MHz 4.2239028 MHz
2 Mb/s
+ 50 ppm 1.0240440 MHz 1.0240584 MHz
- 50 ppm 1.0239416 MHz 1.0239560 MHz
704 kb/s (UKK only)
+ 50 ppm 352.0151 kHz 352.0201 kHz
- 50 ppm 351.9799 kHz 351.9849 kHz
PDH Transmitter Output
Unbal 704 kb/s (UKK
only)
3-11 Step 6: +ve Pulse Amp 2.133 V pk 2.607 V pk
+ve Pulse Width 639 ns 781 ns
Overshoot 0.474 V
Undershoot 0.474 V
3-11 Step 7: -ve Pulse Amp 2.133 V pk 2.607 V pk
-ve Pulse Width 639 ns 781 ns
3-11 Step 7: Overshoot 0.474 V
Undershoot 0.474 V
Bal 704 kb/s
(UKK only)
3-12 Step 10: +ve Pulse Amp 2.133 V pk 2.607 V pk
Table 11 Performance Test Record
Page
No.
Test Description Result
Min Actual Max
To Next Page
