3-90
P
erformance T
ests
STM-1 T
ransmitter Output W
aveshape (Options US1, [US5], A1T
, [A1U],
A3R [A3S], 120)
Figure 3-39
STM-1 Eye Diagram P
attern
Figure 3-40
STM-1 Eye Diagram Mask
NO
TE
If the mask is not a
v
ailable then Figure 3-40 may be traced/copied and compared with
the Oscilloscope print out.
