3-92
P
erformance T
ests
STM-1 Receiver Monitor Input (Options US1, [US5])
Figure 3-41
STM-1 Receiv
er Monitor Input
4.
Press
and select SIGN
AL LEVEL [STM-1] [MONITOR].
5.
V
erify that all the front panel ALARM leds are off.
6.
Press
and
, and check that the
display indicates NO TR
OUBLE.
7.
Press
to halt the measurement.
8.
Disconnect all test equipment.
RECEIVE
RESUL
TS
TROUBLE SCAN
RUN/ST
OP
RUN/ST
OP
200
202
