3-131
Performance Tests
Transmitted Jitter Amplitude Accuracy (Option UHK)
AMPLITUDE to minimum after each change of Bit Rate). Set the HP 37717C
Jitter Modulation Frequency and Amplitude to the values given in columns 2 and 3
of the table. Fine-tune the amplitude to obtain the lowest carrier level on the Spectrum
Analyzer display and check that the jitter amplitude displayed on the HP 37717C is
between the limits given in columns 4 and 5 of Table 3-6.
Table 3-6 Range 10 Tx Jitter Amplitude Accuracy
Bit Rate/
Center
Frequency
Modulation
Frequency
Jitter
Amplitude (UI)
Minimum
Jitter (UI)
Maximum
Jitter (UI)
2048kHz 2400Hz 1.8 1.5 2.0
2048kHz 2400Hz 4.8 4.4 5.1
2048kHz 2400Hz 8.8 8.2 9.3
8448kHz 10700Hz 1.8 1.5 2.0
8448kHz 10700Hz 5.8 5.3 6.2
8448kHz 10700Hz 8.8 8.2 9.3
34368kHz 4000Hz 2.8 2.5 3.0
34368kHz 4000Hz 6.8 6.2 7.3
34368kHz 4000Hz 8.8 8.2 9.3
139264kHz 4000Hz 3.8 3.3 4.2
139264kHz 4000Hz 7.8 7.1 8.4
139264kHz 4000Hz 8.8 8.1 9.4
