3-158
Performance Tests
Wander/Slips Measurement (Options UHN, [US9], A1M [A1Q], A1N
[A1R], A1P [A1S], A3L [A3M], A3V [A3W], A3N [A3P])
25. Press and verify that the display shows the following at the end of
the test period:
26. Select RESULTS [WANDER] [WANDER] and verify that the display shows the
following:
NOTE: In some cases the above two sets of results will all be on the same display.
ESTIMATED BIT SLIPS 955 to
964
ESTIMATED FRAME
SLIPS
3 to 4
RUN/STOP
POSITIVE PEAK 955.125 to 964.875 BITS
NEGATIVE PEAK 0.000 BITS
PEAK TO PEAK 955.125 TO 964.875 BITS
PEAK TO PEAK 15 MINUTE .…BITS
PEAK TO PEAK 24 HOURS .…BITS
TIME INTERVAL ERROR 955.125 to 964.875 BITS
