3-164
Performance Tests
Jitter Receiver STM-1 Optical Interface (Options A1N, [A1R], A3V
[A3W])
10. Verify that the LASER ON led is off before continuing.
11. Disconnect the Optical Attenuator Output from the HP 8153A and connect to the
Optical In Port on the STM Jitter Receiver Module.
12. Press and select SIGNAL [STM-1 OPT].
13. Press and select SDH Jitter. Set signal to [STM-1 OPT].
14. Press and then to start a
measurement.
15. After 5 minutes check that NO TROUBLE is displayed on the
display.
16. Press select STORED SETTINGS NUMBER [0] (Default Settings) and
press .
17. Verify that the LASER ON led is off.
18. Disconnect the test equipment.
TRANSMIT
SDH
RECEIVE
RESULTS
TROUBLE SCAN
RUN/STOP
RESULTS
OTHER
RECALL
