3-214
P
erformance T
ests
STS-3 T
ransmitter Output W
aveshape (Option 120)
Figure 3-63
STS-3 Eye Diagram P
attern
Figure 3-64
STS-3 Eye Diagram Mask
NO
TE
If the mask is not a
v
ailable then Figure 3-64 may be traced/copied and compared with
the Oscilloscope print out.
