3-249

Performance Tests

Performance Test Record

Step 23: Pulse Width Ratio 0.95 1.05

External 2 Mb/s Demux

UKL only

3-65 Step 9: Bit & Code EC Pass/Fail

Step 10: Bit Error Add Pass/Fail

Step 13: +ve Pulse Amp 2.133 V pk 2.607 V pk

3-66 Step 15: +ve Pulse Mask Pass/Fail

Step 19: -ve Pulse Mask Pass/Fail

3-67 Step 20: -ve Pulse Amp 2.133 V pk 2.607 V pk

Step 21: Pulse Amplitude Ratio 0.95 1.05

Step 22: Pulse Width Ratio 0.95 1.05

PDH RX Mon Levels

(Special Option 808)

3-69 Step 7: 704 kb/s (-26 dB) Pass/Fail

3-70 Step 10: 2 Mb/s (-26 dB) Pass/Fail

Step 13: 8 Mb/s (-26 dB) Pass/Fail

Step 16: 34 Mb/s (-29 dB) Pass/Fail

Step 19: 140 Mb/s (-26 dB) Pass/Fail

PDH Error Output

3-72 Step 7: Bit EC Pass/Fail

Step 8: Bit ER Pass/Fail

Step 10: Pulse Period Pass/Fail

Step 11: No Pulses Pass/Fail

Step 12: Alarms On Pass/Fail

Step 14: Pulse Period Pass/Fail

Table 11 Performance Test Record

Page

No.

Test Description Result

Min Actual Max
