3-263

Performance Tests

Performance Test Record

Step 4 Frequency 2048093.2 Hz 2048111.6 Hz.

Step 6 Frequency 2047888.4 Hz 2047906.8 Hz

E3 (34.368Mb/s) Frequency

Accuracy

3-218 Step 2 Frequency 34367845.3 Hz 34368154.7 Hz

Step 4 Frequency 34368532.7 Hz 34368842.0 Hz

Step 6 Frequency 34367158.0 Hz 34367467.3 Hz

3-219 DS1 Frequency Accuracy

Step 2 Frequency 1543992.7 Hz 1544007.3 Hz

Step 4 Frequency 1544042.2 Hz 1544056.7 Hz

Step 6 Frequency 1543943.3 Hz 1543957.8 Hz

Transmitter Output Level and Waveshape (Option 110)

34.368 Mb/s Positive Pulse

3-222 Step 7 Pulse Mask Pass/Fail

3-223 Step 8 peak pulse amplitude 900 mV 1.100 Volts

34.368 Mb/s Negative Pulse

Step 6 Pulse Mask Pass/Fail

Step 7 peak pulse amplitude 900 mV 1.100 Volts

2.048 Mb/s Positive Pulse

3-224 Step 8 Pulse Mask Pass/Fail

Step 9 peak pulse amplitude 2.133V 2.607V

2.048 Mb/s Negative Pulse

3-225 Step 6 Pulse Mask

Step 7 peak pulse amplitude 2.133V 2.607V

DSX-3 Positive Pulse

3-226 Step 7 Pulse Mask Pass/Fail

Table 11 Performance Test Record

Page

No.

Test Description Result

Min Actual Max

HP 37717C Calibration Manual
