1-22
General Information
Specifications
Frequency offset generation:
Up to ±999 ppm in 0.1 ppm steps.
Error addition:
† MSP threshold N errors in T ms
where 0 ≤N ≤1920 (STM-1) and 10 ms
≤T ≤10000 s, in decade steps.
* For SDH stand-alone operation, bulk-
filled payloads and DS1, DS3 mapped
payloads only. For bit error rates
supported with other payloads refer to
the PDH test option for details
Error type Single Rate 10
-N
Comments
Frame A1A2 * N in 4 frame words
B1 * 4 - 9
B2 * 3 - 9
MS REI * 3 - 9
AU-4 path BIP-8 (B3) * 4 - 9
AU-4 path REI * 4 - 9
AU-4 path IEC * 4 - 9
AU-3 path BIP-8 (B3) * 4 - 9
AU-3 path REI * 4 - 9
AU-3 path IEC * 4 - 9
TU-3 path BIP-8 (B3) * 3 - 9
TU-3 path REI * 3 - 9
TU-2 path BIP (V5) * 4 - 9
TU-2 path REI * 5 - 9
TU-12 path BIP (V5) * 3 - 9
TU-12 path REI * 4 - 9
TU-11 path BIP 3 - 9
TU-11 path REI 4 - 9
Bit error * * 3 - 9
