General Information
Specifications
The HP 37717C must be connected
back to back in order to perform a
calibration cycle before making a Jitter
Transfer measurement.
The HP 37717C must have been
switched on for 1 hour before starting a
calibration cycle.
The climatic conditions must remain
stable from switch-on to end of
measurement.
It is recommended that the maximum
test period (start of calibration to end of
measurement) does not exceed 90
minutes.
Test Period = Delay Time + Dwell
Time + 5 Seconds X Number of Points
X 2 (Calibration + Measurement).
Peak Jitter Measurement
These ranges cover the measurements
range specified in O.171, Table3/O.171.
Note that the receiver will be able to
handle transients of up to 24UI(peak)
without losing lock, although the
measurement will be out of range.
On Losing Lock the Jitter Loss LED is
illuminated. If Lock is maintained but
the measurement is out of range then a
Status Message “Jitter Out of Range” is
displayed on the Status Line.
*
7Hz For Rev.A of Options UHK, A1M, A1N, A1P
**
Meets ITU O.171 Table 4.
Receiver Ranges
Range
Lower
UI pp
Upper
UI pp
1.6 0 1.6
16 0 16
Peak Measurement Bandwidth
Bit Rate (Kb/s)
Bandwidth
Min.
*
Max
Range 1.6UI
**
Range 16UI
2048 2Hz 100 kHz 50 kHz
8448 2Hz 400 kHz 100 kHz
34368 2Hz 800 kHz 400 kHz
139264 2Hz 3.5 MHz 800 kHz
155520 2Hz 1.3 MHz 800 kHz
622080 2Hz 5.0 MHz 800 kHz
