Page #72 background imageLoading...
Page #72 background image
1-51
General Information
Specifications
RMS Measurement Accuracy:
*
Only has an effect for 2Mb/s operation.
V = (display resolution)
0.002 UI for range 0.5
0.02 UI for range 5
W= the intrinsic jitter.
Z = the amount of inaccuracy
introduced at high frequency.
Range
Level
(UIrms)
Accuracy
20Hz to 3MHz
Additional
factor >3MHz
0.5UI 0 - 0.1 ± 5% ± V ± W ± Z 5%
0.5UI 0.11 - 0.5 ± 5% ± V ± W ± Z 5%
5UI 0 - 0.1 ± 5% ± V ± W ± Z
*
 5 %
5UI 0.11 - 5.0 ± 5% ± V ± W ± Z
*
 5 %
Bit Rate (kb/s)
Range 0.5
Intrinsic Jitter
(UIrms)
Range 5
Intrinsic Jitter (UIrms)
Clock (all 1’s) PRBS
WWW
2048 0.004 0.03 0.04
8448 0.003 0.03 0.04
34368 0.02 0.04 0.05
139264 0.01 0.03 0.04
155520 (electrical) 0.006 n/a 0.04
155520 (optical) 0.015 n/a 0.04
622080 (optical) 0.02 n/a 0.08
