HP 37717C Calibration Manual

1-63
General Information
Specifications
Alarm indication ATM Layer (All
rates): Loss of cell sync, Selected cell
not received, VP alarm, VC alarm.
Alarm seconds Physical Layer:
2.048 Mb/s, 34.368 Mb/s, 139.264
Mb/s: Power Loss, Loss of Signal,
Loss of Frame, AIS, FERF, RAI.
155.52 Mb/s, 622.08 Mb/s: Loss of
power, Loss of Signal, Loss of frame,
Out of frame, Loss of pointer, MS and
path AIS, K1/K2 change, MS and path
FERF, H4 multiframe, TU loss of
pointer, TU path AIS, TU path FERF.
Alarm seconds ATM Layer (All
rates): Power Loss, Loss of cell sync,
Selected cell not received, Congestion
experienced, Test cell loss, Pattern
Loss, PM OAM loss, VP AIS, VP
FERF, VP LOC, VC AIS, VC FERF,
VC LOC.
ETSI/ANSI Internal Transmitter Clock Rates (Option UKZ)
Rates and Frequency
DS1: 1.544Mb/s:
DS3: 44.736Mb/s
E1: 2.048Mb/s
E3: 34.368Mb/s
Accuracy: DS1 ± 0.7 ppm @ 25C
DS3, E1 and E3 DS1 ± 0.5ppm @ 25C
Temperature stability at all rates:
≤ 3ppm (0 to +50C)
Ageing Stability at all rates:
≤ 1ppm/year
ETSI/ANSI Transmitter Output Level and Waveshape (Option UKZ
Rate Frequency Level Waveshape
DSX-1 1.544Mb/s 3.0V 20% Fits mask T1.102-1993
DS1-LO 1.544Mb/s As DSX-1 with 655' ABAM
Cable
DS3-HI 44.736Mb/s 0.9V pk (nominal)
DSX-3 44.736Mb/s 560mV pk (nominal) Fits mask T1.102-1993
DS3-900 44.736Mb/s 330mV pk (nominal)
E1 (bal) 2.048Mb/s 3.00V 10% As per ITU rec G703
E1 (unbal) 2.048Mb/s 2.37V 10% As per ITU rec G703
E3 34.368Mb/s 1.0V 10% As per ITU rec G703
