HP 409054-003 User Manual

Cascading console switches 24
Main console switch Secondary console switch Tertiary console switch
HP IP Console Switch with
Virtual Media*
HP Server Console Switch with
Virtual Media*
HP Server Console Switch with Virtual Media*
HP IP Console Switch with
Virtual Media*
HP Server Console Switch with
Virtual Media*
HP Server Console Switch, expansion module,
or Compaq Server Console Switch**
HP IP Console Switch with
Virtual Media*
HP Server Console Switch,
expansion module, or
Compaq Server Console
Switch**
—
HP Server Console Switch
with Virtual Media*
HP Server Console Switch with
Virtual Media*
HP Server Console Switch with Virtual Media*
HP Server Console Switch
with Virtual Media*
HP Server Console Switch with
Virtual Media*
HP Server Console Switch, expansion module,
or Compaq Server Console Switch**
HP Server Console Switch
with Virtual Media*
HP Server Console Switch,
expansion module, or
Compaq Server Console
Switch**
—
*Virtual Media capable if a USB 2.0 interface adapter with Virtual Media or a PS2 interface adapter with Virtual
Media is used.
**Does not support Virtual Media.
Cascading two HP Server Console Switches with
Virtual Media and an HP IP Console Switch with
Virtual Media
The following figure shows two HP Server Console Switches with Virtual Media cascaded to an HP IP
Console Switch with Virtual Media. The top console switch is the main console switch, the middle console
switch is the secondary console switch, and the bottom console switch is the tertiary console switch.
