Local port operation 32
To access the Setup dialog box, click Main>Setup. The Setup dialog box appears.
Button Description
Menu Changes the server listing to display numerically by port, numerically by EID number, or
alphabetically by name.
Changes the key combination to launch the OSD.
Flag Changes the type of display, timing, color, and location of the status flag.
Devices Changes the device type from a server to a console switch and identifies the number of ports
on the console switch.
Keyboard Changes the keyboard country code reported by the interface adapter.
Network Changes the network speed and configuration. You can specify the IP address, netmask, and
gateway for the system.
Security Sets password to restrict KVM access. A valid password must be alphanumeric and contain a
minimum of five characters and a maximum of 15 characters. Permitted characters are case-
sensitive and can consist of A–Z, 0–9, spaces, and hyphens.
Enables the Screen Saver mode.
Language Changes the OSD language display.
Names Enables you to name interface adapters.
Scan Sets up custom scan patterns for up to 100 servers.
Preempt Enables a user to preempt another user, remote or local.
Changing the display behavior
From the Menu dialog box, you can change the display order of servers and the key combination used to
launch the OSD. The display order setting alters how servers appear in several places, including the
Main, Devices, and Scan dialog boxes.
