Component identification 7
Interface adapter with Virtual Media components
Interface adapters that support Virtual Media have two LEDs on the front of the RJ-45 connector.
Item Description
1 When lit, this LED indicates that the interface adapter has power from
the server.
2 When lit, this LED indicates that there is an active console session
with the interface adapter.
When flashing, this LED indicates that the interface adapter firmware
is being upgraded.
USB 2.0 interface adapter with Virtual Media
Item Description
1 Video connector
