Page #133 background image
Example: Use the peak table function to measure the calibrator signal and its harmonics.
1. Connect the CAL OUT signal to the spectrum analyzer INPUT 500 and press
[PRESET_).
2.
Press (PEAK SEARCH], More 1 of 2 and PK TABLE ON OFF (ON) to turn on the peak table
display.
3. The displayed peaks are listed by amplitude with the highest amplitude signal listed
first. The table can be sorted by frequency, instead of amplitude. In this mode the lowest
frequency peak is listed first, with the others listed in order of increasing frequency. Press
PK SORT
FRq
AMP to underline FRQ and list the signals by frequency.
4. The harmonics are numbered on the display in order of their listing in the peak table. The
table can be limited to list only the signals above a certain power level. Change the peak
table from the normal mode to the display line mode by pressing PK MODE
<>DL
NRM to
underline >DL. The knob can then be used to move the display line to identify only the
desired peaks above the display line.
5. Press PK MODE
<>DL
MRM again to underline < DL and move the display line to identify
only the peaks that fall below the display line.
Note
The peak table data can be printed by pressing the
[Copv)
key.
The peak table cannot be saved or recalled.
Using Analyzer Features
5-5
