HP 8590 E-Series User Manual

4
PEF .O dBm
ATTEI‘I IO dB
PEAK
LOG
I
1 50 00 MHz 12 0 dB
2 250 0 MHz 10 0 dB
300.0 MHz
WA VB
4 350 0 MHz
SC FC
CENTER 300 0 MHz
SPAN 500 0 MHz
RES BW 3.0 MHz
VBW 1 MHz
SWP 20 msec
pu149a
Figure 5-12. Completed Amplitude-Correction ‘Ihble
9. Press EDIT DONE when all the points have been entered.
Use steps 10 and 11 to display corrected versus uncorrected amplitude trace data for trace
comparison.
10. Display the amplitude-corrected trace in trace A by pressing the following keys:
~~~
CLEAR WRITE A
VIEW A
11. Display the uncorrected amplitude trace in trace B by pressing the following keys:
TRACE A B C until B is selected
CLEAR WRITE B
ICAL), More 1 of 4, More 2 of 4, More 3 of 4, Amp Cor
AMP COR ON OFF until OFF is selected
Using Analyzer Features 5.37
