BLANK
CARD
BND LOCK
ON OFF
Requires Option 003 for an HP
859OL,
HP
8592L,
or HP 8594L.
deletes all the files from the memory card. Pressing BLANK CARD displays
the message: If you are sure, press key again to purge data.
Press
BLANK CARD again if you want to delete all files from the memory card.
Front-Panel Key Access:
(jj
HP
8592L,
HP 85933, HP
8595E,
and HP 8596E only.
underlining ON locks the spectrum analyzer to the lowest frequency band
(local oscillator harmonic number) containing the correct center frequency.
Start and stop frequencies will be changed if necessary. Executing a band lock
limits the spectrum analyzer tuning range to the selected harmonic number.
Selecting the
softkeys
for band 0 through band 4 turns on the band lock
function automatically.
If the start frequency is well within a lower band, turning band lock off will
result, in a multiband sweep. If a specific band had been selected prior to
changing to a multiband sweep, the selected band’s
softkey
label will no longer
be underlined indicating that it is not selected. Sweep of a single band is
indicated by the selected band’s
softkey
label being underlined.
Note
Before changing the frequency range to another harmonic band, unlock the
band by pressing BND LOCK ON OFF so that OFF is underlined.
ICAL)
CAL
AMPTD
Front-Panel Key Access: CFREQUENCY]
activates the resolution bandwidth function and accesses the
softkeys
that
control the bandwidth functions: RES BW AUTO MAN , VID BW AUTO MAN ,
VBW/RBW
RATIO , VID AVG ON OFF , and the
EM1
BW Menu. (Also see the
RES BW AUTO MAN
softkey
description.)
accesses the
softkey
menus used for the self-calibration, service-diagnostics,
and service-calibration functions. For more information about self-calibrating
the spectrum analyzer, see “Improving Accuracy with Self-Calibration
Routines” in Chapter 2.
initiates an amplitude self-calibration routine. Connect CAL OUT to the
spectrum analyzer input before pressing CAL AMPTD . If Option 105 is installed,
remove the cable from the rear panel GATE INPUT before starting the
self-calibration routine.
Note
If the frequency calibration and amplitude calibration self-calibration routines
are both used, the CAL
FREQ
softkey
function should always be initiated
before the CAL AMPTD
softkey
function.
CAL
FETCH
Front-Panel Key Access:
ICAL)
retrieves stored self-calibration correction factors from the last calibration
saved using CAL STORE .
Front-Panel Key Access: (CAL)
Key Descriptions
7-l
